Carrier Class Quality
Carrier class broadband wireless access solution provides scalability, reliability, and superior performance in the most challenging environments.
License Free Long Range Dual Band Operation
Software Selectable 2.4 GHz or 5 GHz operation offers over 20 non-overlapping channels for the most flexible interference free application scenario without the need for regulatory frequency licensing.
Internal and External Antenna Selection
Embedded 15 dBi 5 GHz antenna offers nominal wireless range. If extended range up to 50km is desired, the use of external 2.4 GHz or 5GHz antenna is optional.
Wireless Multimedia
Based on the IEEE 802.11e standard, Wireless multimedia (WMM) provides enhancement for voice and video over IP applications
Rugged Outdoor Weatherproof Design
The IP68 compliant weatherproof enclosure, connectors, and extreme weather rating electronic components continue to perform in the most extreme weather conditions.
Multi-Mode Configuration
Single device with up to four modes of operation: IEEE compliant 802.11a/b/g Access Point, Wireless Bridge, Wireless Repeater, and IEEE compliant 802.11a/b/g Client.
Power over Ethernet
The built-in PoE feature eliminates power connection at the camera location. This eliminates the need of running an additional power line cable.
Integrated RF Site Survey Tool
RF wireless site survey tool built into every radio for simplified frequency planning and installation.
Secure Wireless Transmission
Equipped with Government Strength Advance Encryption System (AES), transmission of top level information is highly secure with the AirEther outdoor wireless system.
|
IR Compatible Dual CCD Day and Night Operation
Automatic color CCD for day and black/white CCD for night time operation. The NVC800 has a video range of 30 meters with integrated IR LED on
High quality real-time monitoring via analog or
digital
network
Stream full motion D1 live color video images across a local
or wide area network. Network connected computers can
access the p/t/z function, monitor, record, and playback
security video with ease
Event driven real-time notification
The integrated sensor input, alarm output, and video motion
detection provides actionable event trigger able to send a
video clip via email or FTP and turn on/off external relays
Synchronized Audio/Video and two-way
audio communication
Audio line in and line out interface(s) with software
selectable audio feature provides synchronized
audiosurveillance and announcement capabilities from the
monitoring station
Integrated IR LED design
70 850nm IR LED lighting provides the best covert
and low light operation
Embedded Streaming Web Server
The suite of function from the embedded streaming web
server makes accessing real-time video easily from any
Internet Explorer enabled computer
IP66 Weather Proof
Reinforced weatherproof
aluminum chassis with heater
and blower to ensure reliable
and durability in the harshest
indoor or outdoor operating
environment |
