lps2000at series

Features | Documents | Application Diagram | Dimensions



Inscape Data's LinkPower 2000AT Series Gigabit IEEE802.3at PoE Switch Systems help customers to stay on top of their business and keep their networks running smoothly. Accelerate their network performance and productivity when you send large real-time video and images to network servers, drives, and wireless Access Points and IP video cameras at Gigabit speed. Power over Ethernet (PoE) 25.5W capability also carries higher electrical power to network devices without the need for additional power outlets.



Key Features



PLUG AND PLAY CONVENIENCE
LinkPower 2000AT Series unmanaged switch offers a quick and easy solution to extend your office network with plug & play installation, 1U Rack mounted design for easy data center installation , automatic adjustment, plug and play, no need software and protocol conversion

GIGABIT PERFORMANCE
LinkPower unmanaged switch offers Gigabit speeds to minimize transfer times and greatly enhance the ability to stream high-bandwidth files to connected devices without interference, All ports support wire-speed switching, frame size within the range of 64 to 1536 can achieve wire-speed

POWER WHERE YOU NEED IT
With IEEE8023af PoE built-in and compliant IEEE 802.3/IEEE 802.3u/ IEEE 802.3x/ IEEE 802.3ab standards to supplying power to 5 classes networking devices such as network hubs, IP phones, and IP cameras can be located anywhere without the need for AC outlets (Maximum power of each port is 15.4W)

NETWORK SURGE PROTECTION
All network ports have lighting-protection function (AC power port: differential mode +/-2kV, common mode +/-4kV)

QUALITY OF SERVICE (QOS) TRAFFIC PRIORITIZATION
QoS traffic prioritization provides the ability to give precedence to particular devices or activities to ensure mission critical data throughput is maintained regardless of network congestion. Auto-sensing ports automatically optimize speed for each connected device (QOS, RSETMSTP, IGMP; RADIUS and 802.1X certification)

UPLINK PORTS FOR EASY NETWORK EXPANSION
All network port 10/100/1000Mbps automatic adjustment RJ45 PoE ports, additionally 2x10/100/1000Mbps Gigabit uplink ports for LinkPower2006AT-2G and 2x 10/100 /1000Mbps SFP fiber uplink ports for LinkPower2016AT-2F & LinkPower2024AT-2F





back to top ^

Documents


Download LinkPower2000AT Series Datasheet





Application Diagram

Dimensions

dimensions
