PoE Ready Camera Housing -
PCH1300HB, PCH2200HB, and PCH3100HB

Inscape Data Corporation now offers a series of new 48V DC power over Ethernet camera housings: PCHB1300-48, PCHB2200-48, and PCHB3100-48.  The new 48VDC PoE camera housing will allow more PoE IP fixed cameras to be used in outdoor environment and complements the existing 12VDC camera housing for most current IP video applications.  The PCH series camera housing is an innovative and stylish video security camera housing designed to simplify installation and maintenance for PoE enabled IP video camera. The new camera housing technology makes use of one Ethernet cable to deliver power to the PoE IP camera and environmental enclosure. The PCH series camera housing offers the following key benefits:

  • Requires only one Ethernet cable to power both the IP video camera and the heater/fan of the camera housing
  • Reduce cabling and installation time
  • Cost saving by eliminating additional power supply


Cable Management
PCHB2200 Standard Enclosure
Extended Length for Optical Camera Lens


12V DC/48V DC
12V DC/48V DC 12V DC/48V DC
Image CHB1300 CHB2200 CHB3100
Housing Model CH100HB
Bracket Model CB300

Fig. 1

Figure 1.  Typical PCH Camera Housing Connection Diagram

The 48V DC PCH series camera housing is compatible with Inscape Data NVC210v2 48V DC PoE Color day night fixed professional IP video security camera and other 3rd party IP cameras  utilizing IEEE802.3af pin configuration and 48VDC PoE technology.  The 12V DC PCH PoE camera housing is compatible with 3rd party PoE IP Camera utilizing 12V DC PoE.  The PCH series camera housing ensures cost effective total protection for your security video investment and is available immediately for purchase through an Inscape Data channel partner.

To inquire more about the PCH series camera housing and other products by Inscape Data, please contact one of Inscape Data's channel partners or Inscape Data directly by e-mail,
